Android Nomad #39 - Database Design using AndroidX Room

In the world of Android development, efficient data management is crucial for creating robust and performant applications. AndroidX Room, a part of the Android Jetpack libraries, provides a powerful abstraction layer over SQLite, making database operations smoother and more intuitive. In this blog post, we'll explore advanced database design techniques using Room, covering key concepts and best practices.

1. Avoiding Duplicates

One of the fundamental principles of good database design is maintaining data integrity by avoiding duplicates. Room provides several ways to ensure uniqueness:

Primary Keys

Use the @PrimaryKey annotation to define a unique identifier for each entity:

@Entity
data class User(
    @PrimaryKey val id: Int,
    val name: String,
    val email: String
)

Unique Constraints

For compound uniqueness, use the @Index annotation with the unique property:

@Entity(indices = [Index(value = ["email"], unique = true)])
data class User(
    @PrimaryKey val id: Int,
    val name: String,
    val email: String
)

2. Using Relations and Foreign Keys

Relations help maintain data consistency across tables. Room supports foreign key relationships:

@Entity(
    foreignKeys = [ForeignKey(
        entity = User::class,
        parentColumns = ["id"],
        childColumns = ["userId"],
        onDelete = ForeignKey.CASCADE
    )]
)
data class Post(
    @PrimaryKey val id: Int,
    val userId: Int,
    val title: String,
    val content: String
)

3. Type Converters

Room allows you to store complex data types by using type converters. Here's an example of storing a Date object:

class Converters {
    @TypeConverter
    fun fromTimestamp(value: Long?): Date? {
        return value?.let { Date(it) }
    }

    @TypeConverter
    fun dateToTimestamp(date: Date?): Long? {
        return date?.time
    }
}

@Database(entities = [User::class, Post::class], version = 1)
@TypeConverters(Converters::class)
abstract class AppDatabase : RoomDatabase() {
    abstract fun userDao(): UserDao
    abstract fun postDao(): PostDao
}

4. ForeignKey Cascade

The onDelete = ForeignKey.CASCADE in the earlier example demonstrates cascading deletes. When a user is deleted, all their posts will be automatically deleted as well. Other options include SET_NULL, NO_ACTION, and RESTRICT.

5. Indices for Performance

Indices can significantly improve query performance, especially for large datasets:

@Entity(indices = [Index(value = ["title"], unique = true)])
data class Post(
    @PrimaryKey val id: Int,
    val userId: Int,
    val title: String,
    val content: String
)

This creates an index on the title column, speeding up searches by title.

6. Querying and Retrieving Data as Flow in ViewModel

Here's how to query and retrieve data as a Flow object in a ViewModel:

@Dao
interface UserDao {
    @Query("SELECT * FROM user")
    fun getAllUsers(): Flow<List<User>>
}

class UserViewModel(private val userDao: UserDao) : ViewModel() {
    val allUsers: Flow<List<User>> = userDao.getAllUsers()
}

7. UI with Jetpack Compose

@Composable
fun UserListScreen(userViewModel: UserViewModel = viewModel()) {
    val users = userViewModel.allUsers.collectAsState(initial = emptyList())

    LazyColumn(
        modifier = Modifier.fillMaxSize(),
        contentPadding = PaddingValues(16.dp)
    ) {
        items(users.value) { user ->
            UserCard(user)
        }
    }
}

@Composable
fun UserCard(user: User) {
    Card(
        modifier = Modifier
            .fillMaxWidth()
            .padding(vertical = 8.dp),
        elevation = 4.dp
    ) {
        Column(
            modifier = Modifier.padding(16.dp)
        ) {
            Text(
                text = user.name,
                style = MaterialTheme.typography.h6
            )
            Spacer(modifier = Modifier.height(4.dp))
            Text(
                text = user.email,
                style = MaterialTheme.typography.body1
            )
        }
    }
}

We collect the Flow of users from the ViewModel using collectAsState(), which converts the Flow into a State that Compose can observe.

---

By leveraging Room's powerful features and following these best practices, you can create efficient, maintainable, and performant database solutions for your Android applications. Remember to always consider your specific use case and optimize accordingly.
